Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
335
3.6.10
TCP/IP Interface object
The TCP/IP Interface object provides the mechanism for configuring the TCP/IP network
interface of the SIMOCODE pro V EtherNet/IP device.
The configured elements include, for example, the IP address, the network mask, the
gateway address and the host name of the device.
● Class code: 0x00F5
● Class attributes: 1, 2, 3
● Number of instances: 1
The instance attributes are defined according to Volume 2 of the CIP Specification. All
instance attributes that are defined as "required" in this specification are supported.
Table 3- 101
General services for the TCP/IP Interface object
Attribute ID
Available service
Service designation
Description
Class
Service
0x01
No
Yes
Get_Attributes_All
Supplies contents of all attributes
0x0E
No
Yes
Get_Attribute_Single
Supplies contents of one attribute
0x10 No Yes Set_Attribute_Single Changes an attribute value
Table 3- 102 Class attributes
Attribute ID
Service
Data type
Name
1
Get
UINT
Revision
2
Get
UINT
Max Instance
3
Get
UINT
Num of Instances
