Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
336 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.6.11
Ethernet Link object
The Ethernet Link object stores link-specific counters and status information for an
IEEE 802.3 communication interface.
● Class code: 0x00F6
● Class attributes: 0
● Number of instances: 3
The instance attributes are defined according to Volume 2 of the CIP Specification.
All instance attributes that are defined as "required" in this specification are supported.
Table 3- 103
General services for the EtherNet Link object
Attribute ID
Available service
Service designation
Description
Class
Service
0x01
No
Yes
Get_Attributes_All
Supplies contents of all attributes
0x0E
No
Yes
Get_Attributes_Single
Supplies contents of one attribute
0x10 No Yes Set_Attributes_Single Changes an attribute value
0x4C
No
Yes
Get_and_Clear
Receive attribute and set to 0
