Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
199
3.3.2.20
Data record 202 - Acyclic receive
Description
The acyclic receive data can be used for any functions. The receive data is available as
device-internal outputs (sockets).
Table 3- 42 Data record 202 - Acyclic receive
Byte.Bit
Designation
Type
Information
0.0
Reserved
Byte[4]
BU0 BU1 BU2(+)
4.0
Acyclic receive - Bit 0.0
Bit
4.1
Acyclic receive - Bit 0.1
Bit
4.2 Acyclic receive - Bit 0.2 Bit
4.3
Acyclic receive - Bit 0.3
Bit
4.4 Acyclic receive - Bit 0.4 Bit
4.5
Acyclic receive - Bit 0.5
Bit
4.6
Acyclic receive - Bit 0.6
Bit
4.7
Acyclic receive - Bit 0.7
Bit
5.0
Acyclic receive - Bit 1.0
Bit
5.1
Acyclic receive - Bit 1.1
Bit
5.2
Acyclic receive - Bit 1.2
Bit
5.3
Acyclic receive - Bit 1.3
Bit
5.4
Acyclic receive - Bit 1.4
Bit
5.5
Acyclic receive - Bit 1.5
Bit
5.6
Acyclic receive - Bit 1.6
Bit
5.7
Acyclic receive - Bit 1.7
Bit
6.0
Acyclic receive - Analog value
Word
