6.5 CBE30 communication board Ethernet
SIMOTION D4x5
102 Manual, 02/2012
6.5 CBE30 communication board Ethernet
6.5.1 CBE30 communication board
Features of the CBE30
The CBE30 Ethernet communication board for SIMOTION D4x5 enables connection to a
PROFINET IO network. The SIMOTION D4x5 then assumes the role of a PROFINET IO
Controller and can offer the following functions:
● PROFINET IO controller, I device (also controller and device simultaneously)
● 100 Mbps full duplex/autocrossing
● Supports real-time classes of PROFINET IO:
– RT (Real Time)
– IRT (isochronous real-time)
The CBE30 has an X1400 interface with an integral 4-port switch based on PROFINET
ASICs ERTEC400.
CAUTION
The CBE30 may only be inserted and removed when the D4x5 Control Unit and CBE30 are
in a de-energized state.
