Supplementary system components
6.4 Controller Extension CX32
SIMOTION D4x5
88 Manual, 02/2012
6.4 Controller Extension CX32
6.4.1 Overview of CX32
Properties
The CX32 is a module in SINAMICS S120 booksize format. The CX32 allows scaling for the
drive-end computing performance of the SIMOTION D435, D445 and D445-1 Control Units.
Each CX32 can control up to 6 additional servo axes, 4 vector axes or 8
V
/
f
axes.
The controller extension has 4 DI, 4 DI/DO and 4 DRIVE-CLiQ interfaces.
Drive quantity structures
If one or more CX32 modules are being used on a SIMOTION D435 or D445/D445-1, the
number of drives that can be used on the SINAMICS Integrated is reduced by one. This
gives the following quantified volumes:
SIMOTION V4.1/V4.2 (SINAMICS V2.5/V2.6)
Table 6- 10 SIMOTION V4.1/V4.2 (SINAMICS V2.5/V2.6) quantity structure
SINAMICS
Integrated
1. CX32 2. CX32 3. CX32 4. CX32
SERVO D435 5+1 (5 drives+
1 ALM
1)
)
6+1 6+1 ----- -----
SERVO
D445/D445-1
5+1 6+1 6+1 6+1 6+1
VEKTOR D435 3+1 4+1 4+1 ----- -----
VECTOR
D445/D445-1
3+1 4+1 4+1 4+1 4+1
V
/
f
D435 7+1 8+1 8+1 ---- ----
V
/
f
D445/D445-1 7+1 8+1 8+1 ---- ----
1)
ALM = Active Line Modules; Basic Line Modules (BLM), and Smart Line Modules (SLM)
can also be used.
