Supplementary system components
6.3 TB30 terminal board
SIMOTION D4x5
80 Manual, 02/2012
6.3 TB30 terminal board
6.3.1 Description
The TB30 Terminal Board is a terminal expansion module for SIMOTION D4x5. It is plugged
into the option slot of the D4x5 Control Unit.
Table 6- 2 Interface overview of the TB30
Type Quantity
Digital inputs 4
Digital outputs 4
Analog inputs 2
Analog outputs 2
6.3.2 Safety information for the TB30
CAUTION
The Terminal Board may only be inserted and removed when the D4x5 Control Unit and
the Terminal Board are de-energized.
CAUTION
The TB30 must only be installed by qualified personnel. The ESD notes must be observed.
For details, see Section ESD guidelines (Page 123).
