Description
1.9 CompactFlash card
SIMOTION D4x5
28 Manual, 02/2012
1.9 CompactFlash card
1.9.1 Usage and function of the CompactFlash Card
The Compact Flash card (CF card) is inserted in the CF plug-in slot (X109 interface).
5HFHVVHGJULSRIWKH&RPSDFW)ODVKFDUG
%ODQNLQJSODWH
Figure 1-7 Slot for Compact Flash card
The CF card does not extent beyond the housing. An ergonomic recessed grip enables the
CF card to be removed.
