Supplementary system components
6.2 Fan/battery module
SIMOTION D4x5
74 Manual, 02/2012
6.2 Fan/battery module
6.2.1 Cooling SIMOTION D4x5 and buffering data
Functions of a fan/battery module
The fan/battery module has the following tasks:
● CPU cooling
● Buffering of the SRAM and the real-time clock if the SuperCap is insufficient.
The Control Unit monitors the temperature and the functioning of the fan.
Cooling the SIMOTION D4x5
If there is insufficient free convection for heat dissipation of the Control Unit and the supply
air temperature rises above the permitted range, an external fan/battery module must be
fitted to the bottom of the D4x5. This module can be installed without further measures on a
Control Unit where there is insufficient ventilation in the control cabinet.
Table 6- 1 Fan/battery module for SIMOTION D4x5
Property SIMOTION
D425
SIMOTION D435 SIMOTION
D445
SIMOTION D445-1
Fan/
battery
module
Optional D435 with order no.
6AU1 435-0AA00-
0AA1: optional
-----------------------------
D435 with order no.
6AU1 435-0AA00-
0AA0:
with supply air
temperature of 43° C
or above
Always required
(included in the
D445's scope of
delivery)
Always required
(double fan/
battery module
included in the D445-
1's scope of delivery)
Compatible
fan/
battery
modules
Fan/
battery module
(single fan)
Fan/battery module
(single fan)
Fan/battery
module (single
fan)
Double fan/
battery module
Fan/battery module
(single fan)
