Supplementary system components
6.9 Terminal modules TM15 and TM17 High Feature
SIMOTION D4x5
112 Manual, 02/2012
6.9 Terminal modules TM15 and TM17 High Feature
Features of TM15 and TM17 High Feature
The TM15 and TM17 High Feature Terminal Modules are used to implement inputs of
measuring inputs and outputs of output cams for SIMOTION D. In addition, these terminal
modules provide drive-related digital inputs and digital outputs with short signal delay times.
TM15 and TM17 High Feature are connected by means of DRIVE-CLiQ.
TM15
Each of the 24 electrically isolated DI/DO can be parameterized channel-by-channel as a
digital input (DI), digital output (DO), input of a measuring input, or output of an output cam.
TM15 DI/DO
Each of the 24 isolated DI/DO can be configured on a channel-specific basis as a digital
input (DI) or digital output (DO). The DI/DO can be interconnected using BICO technology
and thus used from the drive side as well. Unlike the TM15, measuring inputs and outputs of
output cams are not available with the TM15 DI/DO.
Note: The module hardware for the TM15 and TM15 DI/DO is identical. A distinction is only
made by the addition of the component in the SIMOTION SCOUT project navigator using
"Inserting input/output component".
TM17 High Feature
Each of the 16 DI/DO can be parameterized channel-by-channel as a digital input (DI), digital
output (DO), input of a measuring input, or output of an output cam.
TM17 High Feature has fewer I/O channels than TM15, but more functionality. TM17 High
Feature is distinguished by especially high resolution and accuracy as well as a
parameterizable input filter and enabling inputs (max. 6 units). Parameterized enable inputs
can enable measuring inputs or outputs of output cams (gate function). Due to their high
accuracy, the DI/DO channels of the TM17 High Feature are non-isolated.
Note
CAUTION
The 50 mm clearances above and below the components must be observed.
Additional references
You will find further information on TM15 and TM17 High Feature in the
●
TM15/TM17 High Feature System Components
Manual
● Terminal Modules TM15 and TM17 High Feature
Commissioning Manual.
