Supplementary system components
6.5 CBE30 communication board Ethernet
SIMOTION D4x5
Manual, 02/2012
107
6.5.5 Dimension drawing
CBE30 description
The following illustrations show the components in 4 views.
7.5
25.1
15.6


Figure 6-12 Dimensional drawing of the CBE30
