SIMOTION D4x5
Manual, 02/2012
69
Dimension drawings
5
5.1 Dimension drawing of D425 and D435





0
ෘ




6,027,21'


Figure 5-1 Dimension drawing of SIMOTION D425 and SIMOTION D435
The SIMOTION D425/D435 can also be operated without a fan/battery module.
NOTICE
The 80 mm clearances above and below the components must be observed. The unit
protects itself from overheating by shutting down.
