Siemens SIMOTION D4 5 Series User Manual

Dimension drawings
5.2 Dimension drawing of D445
SIMOTION D4x5
70 Manual, 02/2012
5.2 Dimension drawing of D445
6,027,21'










0
Figure 5-2 Dimension drawing of SIMOTION D445
The SIMOTION D445 must always be operated with a fan/battery module.
NOTICE
The 80 mm clearances above and below the components must be observed. The unit
protects itself from overheating by shutting down.
