Supplementary system components
6.7 Terminal module TM41
SIMOTION D4x5
110 Manual, 02/2012
6.7 Terminal module TM41
TM41 characteristics
With the TM41 Terminal Module, the number of available digital inputs/digital outputs and the
number of analog inputs within a drive system can be expanded. In addition, the TTL output
can be used for encoder emulation. The TM41 is connected by means of DRIVE-CLiQ.
The TB41 contains the following terminals:
Table 6- 34 Interface overview
Type Quantity
Digital inputs 4
Digital inputs/outputs 4
Analog inputs 1
TTL encoder output 1
CAUTION
The 50 mm clearances above and below the component must be observed.
Additional references
You will find detailed information about the TM41 terminal module in the
●
SINAMICS S120 Control Units and Supplementary System Components Manual
●
SIMOTION D4x5 Commissioning and Hardware Installation Manual
