Supplementary system components
6.4 Controller Extension CX32
SIMOTION D4x5
96 Manual, 02/2012
6.4.2.4 Power supply
Application
This interface is provided exclusively for connection of an external power supply.
Note
When using external power supplies (e.g. SITOP), the ground potential must be connected
with the protective ground terminal (PELV).
characteristics of the interface
Table 6- 17 Interface X124
Characteristics Type
Connector type Combicon
Connection possibility Up to 2.5 mm
2
Max. current carrying capacity 10 A
Maximum cable length 10 m
Interface assignments
Table 6- 18 Power supply X124
Pin Signal name Signal type Meaning
1 + VI Power supply 24 V
2 + VI Power supply 24 V
3 G VO Ground
4 G VO Ground
Signal type: VI = Voltage input (power supply) VO = Voltage output (power supply)
Note
The 24 V supply voltage is looped through via the 24 V connector. In this case, pin 1 is
jumpered with pin 2, and pin 3 is jumpered with pin 4.
