SIMOTION D4x5
Manual, 02/2012
73
Supplementary system components
6
6.1 Supplemental system components
Additional system components
The following figure shows the connection of the supplementary system components. The
connection is:
● Directly on the SIMOTION D module (fan/battery module)
● Via the option slot (TB30/CBE30)
● Via the DRIVE-CLiQ interfaces (Terminal Modules, Control Unit Adapter, etc.)
7%RU
&%(RSWLRQDO
)DQEDWWHU\PRGXOH
'5,9(&/L4LQWHUIDFHV
IRUWKHFRQQHFWLRQRIV\VWHP
FRPSRQHQWV
2SWLRQVORWZLWKFRYHU
IRUPRXQWLQJRIWKH
7%RU&%(
Figure 6-1 Position of supplementary D4x5 system components
