Type Quantity
Analog inputs 1
TTL encoder output 1
NOTICE
Overheating if ventilation clearances are too small
Insu󹪟cient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
For further information on the TM41 Terminal Module, see the SIMOTION D410-2
Commissioning and Hardware Installation Manual.
7.4 TM54F terminal module
Characteristics
The TM54F Terminal Module is a terminal expansion module for snapping on to a DIN EN 60715
mounting rail. The TM54F o󹪜ers safe digital inputs and outputs for control of Safety Integrated
functions of SINAMICS.
A SIMOTION D410‑2 can be assigned exactly one TM54F which is connected via DRIVE-CLiQ.
The TM54F Terminal Module is an alternative to using Safety Integrated functions via the
onboard terminals (F‑DI, F‑DO) or via PROFIsafe.
Interfaces
Table 7-4 The following terminals are located on the TM54F:
Type Quantity
Fail-safe digital outputs (F‑DO)
1)
4
Fail-safe digital inputs (F‑DI)
2)
10
Sensor power supplies, can be made dynamic
3), 4)
2
Spare parts / accessories
7.4 TM54F terminal module
SIMOTION D410-2
102 Equipment Manual, 07/2021, A5E33446720B
