4.3 PROFIBUS DP interfaces
Properties
SIMOTION D410-2 provides the following interfaces for connection on the PROFIBUS DP:
Table 4-6 SIMOTION D410-2 PROFIBUS interfaces
D410-2 DP D410-2 DP/PN
PROFIBUS DP/MPI interface X21 X21
PROFIBUS DP interface X24 –
The interfaces can be run asynchronously or isochronously, equidistant.
SIMOTION D410-2 includes master and I-slave functionality.
Interface characteristics
Table 4-7 X21 and X24 interfaces
Characteristics Type
Connector type 9-pin sub D socket
Cable type PROFIBUS cable
Max. cable length 100 m at 12 Mbit/s
Max. data rate 12 Mbit/s
Interfaces
4.3 PROFIBUS DP interfaces
SIMOTION D410-2
50 Equipment Manual, 07/2021, A5E33446720B
