• SIMATIC controllers with PROFIBUS DP interface

• Distributed I/O

• Teleservice adapter

• Drive units with PROFIBUS DP interface (standard slaves)

Note

For remote diagnosis, a teleservice adapter can be connected to the PROFIBUS X21 or X24

interface. A teleservice adapter can only be connected to one of the two interfaces.

The power supply for the teleservice adapter (terminals 2 and 7) can accept current loads as

high as 150 mA and is sustained short-circuit proof.

4.4 PROFINET IO interface (SIMOTION D410-2 DP/PN only)

Properties

PROFINET is an open component-based industrial communication system using Ethernet for

distributed automation systems.

SIMOTION D410‑2 DP/PN has a PROFINET interface with two ports (X150 P1-P2) onboard. The

PROFINET interface supports operation of a SIMOTION D410‑2 DP/PN as an IO controller and/or

as an I device.

Interface characteristics

Table 4-10 Ports X150 P1 to P2

Characteristic Type

Connector type RJ45 socket connector

Cable type PROFINET

Maximum cable length 100 m

Minimum send cycle clock 0.25 ms

Autocrossing Yes

i.e. both crossed and uncrossed cables can be used

Dust protection 󹪝ller plugs for seal‐

ing unused PROFINET ports

One 󹪝ller plug contained in the D410‑2 scope of delivery

Filler plugs (50 pcs) article number: 6SL3066‑4CA00‑0AA0

Interfaces

4.4 PROFINET IO interface (SIMOTION D410-2 DP/PN only)

SIMOTION D410-2

52 Equipment Manual, 07/2021, A5E33446720B
