Siemens SIMOTION Equipment Manual

Examples:
• SINAMICS S120 Advanced Position Control (APC)
Article no. 6SL3074-0AA05-0AA0
License for each drive (on CU, SINAMICS Integrated)
• SINAMICS S120 cogging torque compensation
Article no. 6SL3074-0AA15-0AA0
License for each drive (on CU, SINAMICS Integrated)
• SINAMICS Technology Extension "Vibration Extinction" (VIBX)
Article no. 6SL3077-0AA00-5AB0
License for a target device (CU, SINAMICS Integrated)
• SINAMICS DCB Extension
Article no. 6SL3077-0AA00-0AB0
License for a target device (CU, SINAMICS Integrated)
With SINAMICS licenses, underlicensing of SINAMICS Integrated is indicated by the 󹪞ashing SF
LED on the SIMOTION D Control Unit. An entry is also made in the diagnostic bu󹪜er and the
underlicensing is displayed in the License dialog box of SIMOTION SCOUT. The licensing is
performed (as for SIMOTION licenses) via SIMOTION SCOUT or via the SIMOTION license key on
the CF card.
2.8 Data matrix code
SIMOTION D components (e.g. CF cards, Control Units, etc.) have a machine-readable
identi󹪝cation in the form of a data matrix code (2D code).
Reader units that support the data matrix code according to ECC 200 are suitable for reading the
code used here.
Example of a data string from the reader:
1P6AU1400-1QA20-0AA0-Z+ST-LDBN05403+30S012610D2609U2416
The volume of the information contained in the data matrix code depends on the product and,
for example, on the available space.
Table 2-7 Machine-readable identi󹪝cation via 2D code
Characteristic Property (example)
Article number
("1P" identi󹪝er to identify the products)
6AU1400-1QA20-0AA0-Z
Serial number
("S" identi󹪝er, item number)
T-LDBN05403
Hardware serial number (CF cards only)
("30S" identi󹪝er)
012610D2609U2416
Hardware version
(identi󹪝er 2PE)
Not used in the example
Material number
(identi󹪝er P)
Not used in the example
Description
2.8 Data matrix code
SIMOTION D410-2
36 Equipment Manual, 07/2021, A5E33446720B
