Permanent process image for BackgroundTask (I/O
variables)
64 bytes
Additional con󹪝gurable process image for each cyclic
task (I/O variables)
yes
Address space for each PROFIBUS DP station 244 Byte
SINAMICS Integrated (PROFIBUS Integrated) address
space
512 Byte
Address space for each PROFINET device 1400 Byte
Maximum consistency range
Onboard PROFINET interface X150
For controller-controller direct data exchange 254 bytes
For I-device 1024 bytes (as of V4.4)
254 bytes (< V4.4)
Logical address space: Logical addresses can be assigned in STEP 7 within this space.
Physical address space: Address space with assigned data.
The address space contains all the logical addresses, i.e. also diagnostic addresses, I-device, etc.
Number of slaves/devices
Table 5-11 Number of slaves/devices
Maximum number of slaves per PROFIBUS interface 64
Maximum number of devices for PROFINET 64
5.4.3 Onboard I/Os
Digital inputs
Table 5-12 Technical data for digital inputs
Number of inputs 5
Input voltage
• Rated value
• For signal "1"
• For signal "0"
2)
• 24 VDC
• 15 … 30 V
• -3 … +5 V
Electrical isolation
1)
Yes (via optocoupler)
Current consumption typical at 1 signal level 3.5 mA at 24 V
5 mA at 24 V
3)
Input delay, typical (hardware)
• Signal "0" → "1"
• Signal "1" → "0"
• 50 μs
• 150 μs
Technical data
5.4 Interfaces and performance features
SIMOTION D410-2
Equipment Manual, 07/2021, A5E33446720B 87
