TM15 DI/DO
Each of the 24 isolated digital I/Os can be congured on a channel-specic basis as a digital input
(DI) or digital output (DO). The digital I/Os can be interconnected using BICO technology and
thus used from the drive side as well. Unlike the TM15, measuring input inputs and cam outputs
are not available with the TM15 DI/DO.
Note
The module hardware for TM15 and TM15 DI/DO is identical. A distinction is only made by the
addition of the component in the SIMOTION SCOUT project navigator using "Inserting I/O
component".
TM17 High Feature (only available as spare part)
Each of the 16 digital I/Os can be parameterized channel-by-channel as a digital input (DI),
digital output (DO), measuring input input, or an output cam output.
TM17 High Feature has fewer I/O channels than TM15, but more functionality. TM17 High
Feature is distinguished by especially high resolution and accuracy as well as a congurable
input lter and enabling inputs (max. 6 units). Parameterized enable inputs can enable
measuring inputs or outputs of output cams (gate function). Due to their high accuracy, the
digital I/O channels of the TM17 High Feature are non-isolated.
NOTICE
Overheating if ventilation clearances are too small
Insucient ventilation clearances result in overheating and therefore in more failures and a
shortened life of the component.
Maintain 50 mm ventilation clearances above and below the component.
Additional references
Detailed information about the TM15 and TM17 High Feature can be found in the SIMOTION
Terminal Modules TM15 / TM17 High Feature Commissioning Manual.
7.6 CUA31/CUA32 control unit adapter
Properties
You can connect a Power Module in blocksize format to the DRIVE-CLiQ interface using the
CUA31 adapter module. The CUA32 adapter module also provides an encoder interface for an
HTL, TTL or SSI encoder.
Spare parts / accessories
7.6 CUA31/CUA32 control unit adapter
SIMOTION D410-2
104 Equipment Manual, 07/2021, A5E33446720B
