Integration time / conversion time (per channel)
• Parameters can be assigned
• Integration time
Yes
≥ 62.5 µs
Operational limit (across temperature range, in re‐
lation to the end value of the measuring range in
the input range)
• Voltage input
• Current input
±0.65%
±1.1%
Basic error limit (operational limit at 25° C, in rela‐
tion to the end value of the measuring range in the
input range)
• Voltage input
• Current input
±0.5%
±0.5%
Linearity error (with reference to the input range) ±0.05%
Repeatability (in steady state at 25° C, with refer‐
ence to input range)
±0.05%
When used as analog voltage input
Input voltage range -10 … +10 V
Resolution 12-bit + sign (based on ± 11 V)
1)
Input resistance (R
i
) > 100 kΩ
Temperature error (with reference to the input
range)
±0.005%
When used as analog current input
Input current range -20 … +20 mA
Resolution 11-bit + sign (based on ± 22 mA)
1)
Input resistance (R
i
) 250 Ω
Temperature error (with reference to the input
range)
±0.02%
1)
The maximum controllable area is approx. ± 11 V or ± 44 mA
The resolution refers to the specied area (irrespective of the engineering settings).
5.4.4 Onboard encoder interface
Table 5-17 Technical data of the encoder interface
Encoder interface
• TTL or HTL incremental encoders (with adjustable param‐
eters)
• Absolute encoder
Power supply 24 VDC / 0.35 A or
5 VDC / 0.35 A
Short-circuit and overload proof
Limit frequency 500 kHz
SSI baud rate 100 ... 1000 kBaud
