The parameter belongs to the unit group 7_1 and p0505 changes over the unit.

Table 8-39 Unit group (p0100)

Unit group Unit selection for p0100 =

0 1 2

7_4 Nm lbfft Nm

14_6 kW hp kW

25_1 kgm² lbfft² kgm²

27_1 kg lb kg

28_1 Nm/A lbfft/A Nm/A

Table 8-40 Unit group (p0505)

Unit group Unit selection for p0505 = Reference value for %

1 2 3 4

2_1 Hz % Hz % p2000

3_1 rpm % rpm % p2000

5_1 Vrms % Vrms % P2001

5_2 V % V % p2001

5_3 V % V % p2001

6_2 Arms % Arms % p2002

6_5 A % A % p2002

7_1 Nm % lbfft % p2003

7_2 Nm Nm lbfft lbfft -

14_5 kW % hp % r2004

14_10 kW kW hp hp -

21_1 °C °C °F °F -

21_2 K K °F °F -

39_1 1/s² % 1/s² % p2007

8.15.3 Technological unit of the technology controller

Options when selecting the technological unit

p0595 de󹪝nes in which technological unit the input and output variables of the technology

controller are calculated, e.g. [bar], [m³/min] or [kg/h].

Reference variable

p0596 de󹪝nes the reference variable of the technological unit for the technology controller.

Advanced commissioning

8.15Selecting physical units

SINAMICS G120C Converters

Operating Instructions, 02/2023, FW V4.7 SP14, A5E34263257B AK 253
