Communication
11.4 DR 3 Belt scale parameters
SIWAREX WT241
102 Manual, 05/2015, A5E36046748A
11.4.3 Unit for belt load
When setting parameters for the first time you must select between metric and imperial
systems.
The following units can be selected for the belt load:
0 – kg/m (metric)
1 – lbs/foot (imperial)
With the kg/m unit, the material flow rate can be specified in t/h or kg/h.
With the lbs/foot unit, the material flow rate can be specified in T/h, TL/h or lbs/h.
Note
If the jumper is closed to protect data with verification capability, the parameter can no longer
be changed.
11.4.4 Unit for flow rate
The following units can be selected for the material flow rate:
0 – t/h (metric)
1 – kg/h (metric)
2 – T/h (imperial)
3 – TL/h (imperial)
4 – lbs/h (imperial)
Note
If the jumper is closed to protect data with verification capability, the parameter can no longer
be changed.
11.4.5 Resolution of weight and belt load
The resolution for the weight measurement and the belt load per length unit can be defined
in accordance with the standard EN 45501 (1*10**k, 2*10**k, 5*10**k]; k: -3 … 2) from
0.0001 to 50.
Note
If the jumper is closed to protect data with verification capability, the parameter can no longer
be changed.
