Scale parameters and functions of the belt scale
8.11 Menu 2.3 Flow trend
SIWAREX WT241
76 Manual, 05/2015, A5E36046748A
Weight
The current material weight of the loaded belt resting on the
scale. The output is made in the selected weight unit from the
belt load.
Drag indicator (belt load)
Maximum measured belt load
Nominal belt load
The nominal belt load is entered during initial commissioning. It
is the basis for generating limits, and is calculated from design
flow rate / design speed.
Current zero offset
Current difference compared to original zero (under load)
Current zero offset (%)
Current difference compared to original zero (% of nominal belt
load)
No. of zero settings
Number of zero settings, combines manual and automatic zero
settings. Will be reset with restoring the default values.
8.11 Menu 2.3 Flow trend
The flow trend is a graphical presentation of the flow rate. The graph will be scaled
automatically based on the given values.
8.12 Menu 2.4 Module information
2.4.1 Modul information
General information about the SIWAREX WT241
Order number
Order number of the weighing module used in the terminal.
Serial number
Serial number of the weighing module used in the terminal.
Version
Version of hardware and software
Version HMI-project
Version of the user interface software
Support hotline
Call this number to get technical support by telephone:
+49 721 595 2811
Support e-mail
Technical support regarding SIWAREX products per e-mail:
hotline.siwarex@siemens.com
