Communication
11.23 DR 30 Process state
SIWAREX WT241
Manual, 05/2015, A5E36046748Aa 155
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
1003
Checksum error data
BIT
0
r
0
-
-
3006.7
Reserve
Reserve
BIT
0
r
0
-
-
3006.6
1004
Checksum error program
BIT
0
r
0
-
-
3006.5
Reserve
BIT
0
r
0
-
-
3006.4
1001
Watchdog
BIT
0
r
0
-
-
3006.3
1007
BIT
0
r
0
-
-
3006.2
Reserve
BIT
0
r
0
-
-
3006.1
2000
Group message "Technological
error" present
BIT
0
0
0
-
-
3007.16
Reserve
Reserve
BIT
0
r
0
-
-
3007.15
2002
Trace overloaded
BIT
0
r
0
-
-
3007.14
2003
Zeroing not possible
BIT
0
r
0
-
-
3007.13
3001
Fault during totalizing
BIT
0
r
0
-
-
3007.12
2004
Trace memory full
BIT
0
r
0
-
-
3007.11
3002
Calibration aborted
BIT
0
r
0
-
-
3007.10
Current weight
(Page 155)
FLOAT
4
r
0
-
-
3008
Current belt load
(Page 156)
Current belt load in weight unit
per length unit
FLOAT
4
r
0
-
-
3010
Current belt load in %
(Page 156)
Current belt load in % of nomi-
nal belt load
FLOAT
4
r
0
-
-
3012
Current flow rate
(Page 156)
Current material flow rate per
hour
FLOAT
4
r
0
-
-
3014
Current flow rate in %
(Page 156)
Current material flow rate in %
of nominal flow rate
FLOAT
4
r
0
-
-
3016
Current speed
(Page 156)
Current speed per second
FLOAT
4
r
0
-
-
3018
Current speed in %
(Page 156)
Current speed in % of design
speed
FLOAT
4
r
0
-
-
3020
Current master totaliz-
er (S1) (Page 156)
Current master totalizer (total
operating time)
DOUBLE
8
r
0
-
-
3022
Current main totalizer
(S2) (Page 156)
Current main totalizer
FLOAT
4
r
0
-
-
3026
Reserve
FLOAT
4
r
0
-
-
3028
Refresh counter for
process values
(Page 157)
Refresh counter incremented
by 1 if weight values were
changed
USHORT
2
r
0
-
-
3030
Reserve 1
Reserve
SHORT
2
r
0
-
-
3031
Reserve 3
Reserve
FLOAT
4
r
0
-
-
3032
11.23.1 Current weight
The current material weight of the loaded belt resting on the scale. The output is made in the
selected weight unit from the belt load.
