Communication
11.28 DR 38 Process state extended
SIWAREX WT241
168 Manual, 05/2015, A5E36046748A
11.28 DR 38 Process state extended
The data record contains scale-specific parameters.
Procedure
● Read data record DR 38
● Display/analyze the required tags
Table 11- 28 Assignment of data record 38
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record number
Contains no. of data rec-
ord
USHORT
2
r
38
-
-
4500
Length
Data record length infor-
mation
USHORT
2
r
64
-
-
4501
Application
Information about which
application the data record
belongs to
USHORT
2
r
104
-
-
4502
Version identifier
Information about current
data record version
USHORT
2
r
1
1
65635
4503
Counter zeroing
Number of implemented
zeroing procedures, re-
cording of manual and
automatic zeroing proce-
dures (is reset when load-
ing the factory settings)
ULONG
4
r
0
4504
Counter initial zero calibration
Number of implemented
initial zero calibration pro-
cedures (is reset when
loading the factory set-
tings)
ULONG
4
r
0
4506
Counter span calibration
Number of implemented
span calibration proce-
dures (is reset when load-
ing the factory settings)
ULONG
4
r
0
4508
Drag indicator (belt load)
Maximum belt load that
has occurred
FLOAT
4
r
0
4510
Reserve
LONG
4
r
0
4512
Current initial zero offset
(belt load)
Current deviation from
original zero (when load-
ed)
FLOAT
4
r
0
4514
Current initial zero offset
(in % of nominal load)
Current deviation from
original zero (in % of nom-
inal load)
FLOAT
4
r
0
4516
Reserve
FLOAT
4
r
0
4518
Reserve
LONG
4
r
0
4520
Reserve
LONG
4
r
0
4522
Reserve
LONG
4
r
0
4524
Reserve
3xLONG
LONG
12
0
4526
