11.26 DR 33 Totalizers
SIWAREX WT241
164 Manual, 05/2015, A5E36046748A
11.26 DR 33 Totalizers
Data record DR 33 contains the actual values of the totalizers.
Totalizing becomes active when the minimum belt load for the totalizer (parameter in DR6)
has been exceeded. Command 652 can be used to stop all totalizers except S6. Command
651 starts totalizing again.
Table 11- 26 Assignment of data record 33
Variable
Note
Type
L
Rw
Default
Min.
Max.
Regis-
ter
Data record num-
ber
Contains no. of data record
USHORT
2
r
33
-
3514
Length
Data record length information
USHORT
2
r
44
-
3515
Application
Information about which application the
data record belongs to
USHORT
2
r
104
-
3516
Version identifier
Information about current data record
version
USHORT
2
r
1
3517
Current master
totalizer (S1)
(Page 164)
Master totalizer (S1) since commissioning
of the scale
DOUBLE
8
r
0
3518
Current main total-
izer (S2)
(Page 164)
Current main totalizer (S2)
FLOAT
4
r
0
3522
Reserve
-
FLOAT
4
r
0
3524
Totalizer 3 (S3),
totalizer 4 (S4),
totalizer 5 (S5)
(Page 165)
Totalizer S3
FLOAT
4
r
0
3526
Totalizer S4
FLOAT
4
r
0
3528
Totalizer S5
FLOAT
4
r
0
3530
Totalizer 6 (S6)
(Page 165)
Totalizer S6
FLOAT
4
r
0
3532
Reserve
-
FLOAT
4
r
0
3534
11.26.1 Current master totalizer (S1)
This totalizer contains the total of conveyed material since commissioning of the scale. The
master totalizer can only be reset by loading the factory settings.
11.26.2 Current main totalizer (S2)
The totalizer contains the quantity of material transported since the last memory reset. The
operating total must be logged in the case of trade scales requiring verification (available
soon). You can reset the total using command 670.
