Siemens SIWAREX WT241 User Manual

Communication
11.16 DR 15 belt angle
SIWAREX WT241
144 Manual, 05/2015, A5E36046748A
11.16 DR 15 belt angle
Data recorder DR 15 is used for an external specification.
Procedure
● Enter the actual inclination angle of the conveyor belt.
● Transfer the data record to the scale.
Table 11- 16 Assignment of data record 15
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record num-
ber
Contains no. of data record
USHORT
2
r
15
-
-
1570
Length
Data record length information
USHORT
2
r
16
-
-
1571
Application
Information about which appli-
cation the DR belongs to
USHORT
2
r
104
-
-
1572
Version identifier
Information about current data
record version
USHORT
2
r
1
1
65635
1573
Current belt angle
(Page 144)
Angle of inclination
FLOAT
4
rw
0
0
60
1574
Reserve 1
Reserve
SHORT
2
rw
0
0
-
1576
11.16.1 Current belt angle
Input of the angle is provided for belt scales where the inclination of the belt can be changed
during operation. Calculation of the current belt load is corrected by entering the current
angle.
The input is unnecessary if the inclination is always constant: the influence of the constant
angle is compensated or automatically taken into consideration during the calibration with
weights or test chain.
If the scale is automatically calibrated using the load cell parameters and if the scale is not
installed exactly horizontally, you must subsequently enter the inclination angle of the belt.
The input is made in degrees.
