Communication
11.15 DR 13 RS485 parameters
SIWAREX WT241
140 Manual, 05/2015, A5E36046748A
11.15 DR 13 RS485 parameters
The parameters which define the response of the RS485 interface are specified in data
record DR 13. If the interface is not used, the default values can be retained.
Procedure
● Check the parameters and modify them as required
● Transfer the data record to the scale
Table 11- 15 Assignment of data record 13
Variable
Note
Type
L
Rw
Default
Min.
Max.
Register
Data record
number
Contains
no. of data
record
USHORT
2
r
13
-
-
1558
Length
Data record
length in-
formation
USHORT
2
r
24
-
-
1559
Application
Information
about which
application
the data
record
belongs to
USHORT
2
r
104
-
-
1560
Version
identifier
Information
about cur-
rent data
record
version
USHORT
2
r
1
1
65635
1561
RS485
protocol
(Page 141)
0: No pro-
tocol
1:
MODBUS
RTU
USHORT
2
rw
1
0
2
1562
RS485
baud rate
(Page 142)
2: 9
600 bps
3: 19
200 bps
4: 38
400 bps
5: 57
600 bps
6:115 000 b
ps
USHORT
2
rw
3
0
6
1563
RS485
character
parity
(Page 142)
Character
parity
0: Even
1: Odd
BIT
0
rw
0
0
1
1564.16
