Connecting
6.1 Overview
SIWAREX WT241
Manual, 05/2015, A5E36046748A 23
6 Connecting
6
WARNING
High voltage
Switch off the machine so that it is in a no-voltage condition before you open the terminal box.
6.1 Overview
The weighing terminal SIWAREX WT241 comes with a number of connection options. It is
equipped with EMC safe cable glands for the major connections (mains and load cells).
Figure 6-1 SIWAREX WT241 overview
①
Stainless steel enclosure
②
SIMATIC KTP400 basic color PN color touch
display
③
Fastening screws
④
Lugs for wall fastening
⑤
Connection area
