Communication
11.25 DR 32 display of data and operator errors
SIWAREX WT241
Manual, 05/2015, A5E36046748Aa 161
11.25 DR 32 display of data and operator errors
Data record DR 32 is used for Modbus communication with a Modbus master. If a function
which is used to write to the holding register is completed with an error, the data or operator
error reported can be read from data record DR 32. Messages are displayed for at least
three seconds and do not need to be acknowledged in the SIWAREX module.
Data record DR 32 does not need to be polled upon positive completion of a function for
writing to the SIWAREX register.
Table 11- 25 Assignment of data record 32
Contains no. of data record
Data record length information
Information about which application the
data record belongs to
Information about current data record
version
Data or operating error exists
Command code or data record unknown
Command or data change not possible
because write protection is active
Leaving calibration mode not possible
Command or data transmission only avail-
able in service mode
Command or data transmission not possi-
ble because service mode is active
Command or data transmission not possi-
ble because BUSY
Command or data transmission not possi-
ble because module is faulty or ODIS is
active
Command not possible since memory is
full (concerns the trace function)
Command is not permissible in this oper-
ating state
Command not possible because range is
exceeded
Load cell parameter not plausible
Shifting characteristic not possible
