119 / 176
Siemens Web server OZW772... V6.0 CE1C5701en
Building Technologies Trend functions 2015-10-12
9 Trend functions
9.1 Overview
The Web-Server OZW772... can create trends for any data points. The trend can
be labeled with its own name and the sampling rate set. The maximum period of
trending is derived from the number of data points selected and the sampling rate.
A web browser is used to set the trend.
As an alternative, you can also set trends via the ACS Tool.
· Select the Web Server.
The Home page is displayed.
· Under primary navigation, select File transfer menu.
In secondary navigation on the left side of the window, the overview page Trend for
the Web Server is automatically selected.
Trend overview appears as follows if not trend has been defined:
Trend overview appears as follows if trends have already been defined:
An active trend is highlighted in green.
Select trend function
