Siemens Synco OZW772 Series User Manual

66 / 176
Siemens Web server OZW772... V6.0 CE1C5701en
Building Technologies Visualize plants 2015-10-12
5.4 Toolbar
The menus described below are only displayed and operable on the
"Administrator" user level.
The following toolbar is displayed at home and on the device nodes, if no plant
web pages are generated:
Menu Description (in German)
New Create new plant web page.
Import Import archived plant web page.
Plant web pages are archived and imported as .tar files.
The toolbar is as follows for an existing plant web page:
Menu Description (in German)
Properties Properties dialog for the plant web page. Enter the same as for
"New".
Furthermore, "Replace data point addresses" address identical
data points on another device (KNX address).
New Create another plant web page.
Import Import archived plant web page.
Edit Switch to edit.
Copy Copy selected plant web page to another device node.
Export Export selected plant web page as .tar archive.
Delete Deleted selected plant web page.
Click Edit to switch the plant web page to edit mode. The toolbar is as follows:
Only an administrator may generate and change visualization. User levels have the
same rights for operation and monitoring.
Note
View mode, no web
page available
View mode, web page
available
Edit
Menu Description (in German)
Data point Embed data point element to web page.
A data point element consists of two fields:
· Data point value for a device connected via KNX or the Web
Server.
· Data point text.
Text Add free text (single line) to plant web page. The text is entered
in the field "Displayed name".
Link Hyperlink to other plant web pages, to a document or an
external web page.
Partial picture Add additional picture to plant web page. "Link external" inte-
grates periodically updated, external images (e.g. web cams).
User levels
