5-17
1-3. CAMERA SYSTEM ADJUSTMENTS
Before perform the camera system adjustments, check that the
specified values of “VIDEO SYSTEM ADJUSTMENTS” are
satisfied.
Note: NTSC model: DCR-TRV730/TRV828/TRV830
PAL model: DCR-TRV725E/TRV730E/TRV828E/TRV830E
1. HALL Adjustment
For detecting the position of the lens iris, adjust AMP gain and
offset.
Subject Not required
Measurement Point Display data of page 1 (Note1)
Measuring Instrument Adjustment remote commander
Adjustment Page A
Adjustment Address 17, 18, 19
Specified Value 1 14 to 18
Specified Value 2 86 to 8B
Note1: Displayed data of page 1 of the adjustment remote commander.
1 : 00 : XX
IRIS display data
Switch setting:
POWER.................................................................. CAMERA
Adjusting method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 A 17 80 Set the data, and press PAUSE
button.
3 A 18 8C Set the data, and press PAUSE
button.
4 6 94 16 Set the data.
5 6 95 88 Set the data.
6 6 08 6D Set the data, and press PAUSE
button.
7 6 09 Check that the data changes to
“01”. (Note2)
8 6 08 00 Set the data, and press PAUSE
button.
Note2: The adjustment data will be automatically input to page: A, address:
17, 18, 19.
Checking method:
Order Page
Address
Data Procedure
1 6 0B 03 Set the data.
2 6 08 00 Set the data, and press PAUSE
button.
3 6 08 01 Set the data, and press PAUSE
button.
4 1 Check that the IRIS display data
(Note1) satisfies the specified
value 1.
5 6 08 03 Set the data, and press PAUSE
button.
6 1 Check that the IRIS display data
(Note1) satisfies the specified
value.2.
Processing after Completing Adjustments:
Order Page
Address
Data Procedure
1 6 94 00 Set the data.
2 6 95 00 Set the data.
3 6 08 00 Set the data, and press PAUSE
button.
4 6 0B 00 Set the data.
5 0 01 00 Set the data.
