6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< RESISTOR >
R701 1-218-883-11 METAL CHIP 33K 0.5% 1/16W
R702 1-218-901-11 METAL CHIP 180K 0.5% 1/16W
R703 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R704 1-211-985-11 METAL CHIP 47 0.5% 1/16W
R705 1-216-821-11 METAL CHIP 1K 5% 1/16W
R706 1-216-839-11 METAL CHIP 33K 5% 1/16W
< THERMISTOR >
TH701 1-810-811-11 THERMISTOR, NTC (1608)
************************************************************
A-7074-760-A MM-043 BOARD, COMPLETE
**********************
(Ref. No.;10000 Series)
< CAPACITOR >
C7301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7302 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7308 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7314 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7315 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7316 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN7301 1-774-603-21 CONNECTOR, BOARD TO BOARD 100P
CN7302 1-779-330-21 CONNECTOR, FFC/FPC 12P
< DIODE >
D7301 8-719-056-85 DIODE UDZSTE-178.2B
< FERRITE BEAD >
FB7301 1-500-282-11 FERRITE 0UH
FB7302 1-500-329-21 FERRITE 0UH
FB7304 1-500-329-21 FERRITE 0UH
FB7306 1-500-329-21 FERRITE 0UH
< IC >
IC7301 6-700-134-01 IC NT56V1616A0T-7-T&R
IC7304 6-700-134-01 IC NT56V1616A0T-7-T&R
IC7305 8-759-835-18 IC MBM29LV400BC-90PFTN-S115-ER
< RESISTOR >
R7301 1-216-805-11 METAL CHIP 47 5% 1/16W
R7303 1-216-845-11 METAL CHIP 100K 5% 1/16W
R7304 1-216-845-11 METAL CHIP 100K 5% 1/16W
R7305 1-216-295-11 SHORT 0
R7306 1-216-295-11 SHORT 0
************************************************************
A-7074-646-A PD-138 (XS6) BOARD, COMPLETE (TRV730)
************************************
(Ref. No.;10000 Series)
< CAPACITOR >
C5501 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C5503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C5510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5514 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C5515 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C5516 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C5517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5519 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5520 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C5521 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C5524 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C5527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5528 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C5530 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5602 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN5501 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5604 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-794-998-21 PIN, CONNECTOR 20P
CN5703 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN5704 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN5705 1-779-335-21 CONNECTOR, FFC/FPC 22P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-073-01 DIODE MA111-(K8).S0
D5601 8-719-073-01 DIODE MA111-(K8).S0
< FERRITE BEAD >
FB5502 1-414-760-21 FERRITE 0UH
FB5503 1-414-760-21 FERRITE 0UH
FB5504 1-414-760-21 FERRITE 0UH
MM-043LB-071 PD-138
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
