Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< CONNECTOR >
CN5501 1-573-364-11 CONNECTOR, FFC/FPC 24P
CN5501 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
* CN5502 1-573-984-11 CONNECTOR, BOARD TO BOARD 10P
CN5604 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN5701 1-794-998-21 PIN, CONNECTOR 20P
CN5703 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN5704 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN5705 1-779-335-21 CONNECTOR, FFC/FPC 22P
< DIODE >
D5502 8-713-102-80 DIODE 1T369-01-T8A
D5503 8-719-050-42 DIODE RD3.3UM-T1B
D5601 8-719-073-01 DIODE MA111-(K8).S0
< FERRITE BEAD >
FB5502 1-500-328-22 FERRITE 0UH
FB5504 1-500-328-22 FERRITE 0UH
< IC >
IC5501 8-752-100-84 IC CXA3579R-T4
IC5502 8-752-407-33 IC CXD3512R-T4 (TRV725E/TRV730E)
IC5502 8-752-409-15 IC CXD3516R-T4
(TRV828/TRV828E/TRV830/TRV830E)
IC5601 8-759-564-49 IC TC7W53FU(TE12R)
IC5602 8-759-075-70 IC TA75S393F-TE85R
IC5701 8-759-573-02 IC BU9735K-E2
< COIL >
L5501 1-469-525-91 INDUCTOR 10uH
L5505 1-412-949-21 INDUCTOR 6.8uH
(TRV725E/TRV730E:AEP,UK/TRV828/TRV828E/TRV830/TRV830E)
L5505 1-412-956-21 INDUCTOR 27uH (TRV730E:E,HK,AUS)
L5601 1-419-387-21 INDUCTOR 100uH
< TRANSISTOR >
Q5503 8-759-054-48 TRANSISTOR UP04601008S0
Q5504 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
Q5505 8-729-041-23 TRANSISTOR NDS356AP
Q5506 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q5508 8-759-054-48 TRANSISTOR UP04601008S0
Q5601 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-054-45 TRANSISTOR UP04312008S0
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-893-11 METAL CHIP 82K 0.5% 1/16W
(TRV725E/TRV730E:AEP,UK/TRV828/TRV828E/TRV830/TRV830E)
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
(TRV730E:E,HK,AUS)
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-839-11 METAL CHIP 33K 5% 1/16W
(TRV725E/TRV730E:AEP,UK)
R5553 1-216-841-11 METAL CHIP 47K 5% 1/16W
(TRV828/TRV828E/TRV830/TRV830E)
R5553 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV730E:E,HK,AUS)
R5557 1-216-864-91 SHORT 0
R5571 1-216-809-11 METAL CHIP 100 5% 1/16W
R5572 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5573 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5574 1-218-917-11 RES-CHIP 820K 5% 1/16W
R5575 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5576 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5577 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5579 1-216-847-11 METAL CHIP 150K 5% 1/16W
R5585 1-216-839-11 METAL CHIP 33K 5% 1/16W
R5586 1-216-839-11 METAL CHIP 33K 5% 1/16W
R5587 1-216-839-11 METAL CHIP 33K 5% 1/16W
R5588 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5590 1-216-821-11 METAL CHIP 1K 5% 1/16W
R5591 1-216-864-91 SHORT 0
R5592 1-216-864-91 SHORT 0
R5609 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5612 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-833-11 METAL CHIP 10K 5% 1/16W
(TRV725E/TRV730E)
R5614 1-216-835-11 METAL CHIP 15K 5% 1/16W
(TRV828/TRV828E/TRV830/TRV830E)
R5616 1-216-809-11 METAL CHIP 100 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5712 1-216-855-11 METAL CHIP 680K 5% 1/16W
< TRANSFORMER >
0 T5601 1-435-785-21 TRANSFORMER, INVERTER
************************************************************
A-7074-759-A SI-030 (GT) BOARD, COMPLETE
(TRV730/TRV828/TRV830)
**************************************
A-7074-816-A SI-030 (GM) BOARD, COMPLETE
(TRV725E/TRV730E/TRV828E/TRV830E)
**************************************
(Ref. No.;10000 Series)
< CAPACITOR >
C305 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C306 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C307 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C308 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C309 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
PD-139
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
SI-030
