Sony DCR-TRV725E - FU-155; LB-071

6-14
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FP-332 FU-155 LB-071
< DIODE >
D201 8-719-073-01 DIODE MA111-(K8).S0
< LINE FILTER >
LF201 1-419-100-21 COIL, COMMON-MODE CHOKE
LF202 1-419-100-21 COIL, COMMON-MODE CHOKE
************************************************************
A-7074-758-A FU-155 (GNF) BOARD, COMPLETE
(TRV730/TRV828/TRV830)
**************************************
A-7074-815-A FU-155 (GPF) BOARD, COMPLETE
(TRV725E/TRV730E/TRV828E/TRV830E)
**************************************
(Ref. No.;10000 Series)
< CAPACITOR >
C401 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C402 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C403 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C404 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C405 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C406 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C409 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C410 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN401 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN402 1-750-076-21 CONNECTOR, FFC/FPC 12P
CN403 1-691-520-11 CONNECTOR, BOARD TO BOARD 48P
< DIODE >
D401 8-719-027-76 DIODE 1SS357-TPH3
D402 8-719-062-16 DIODE 01ZA8.2(TPL3)
D404 8-719-056-85 DIODE UDZSTE-178.2B
D405 8-719-062-16 DIODE 01ZA8.2(TPL3)
D406 8-719-062-16 DIODE 01ZA8.2(TPL3)
D407 8-719-062-16 DIODE 01ZA8.2(TPL3)
D408 8-719-027-76 DIODE 1SS357-TPH3
< FUSE >
0F401 1-576-407-21 FUSE, MICRO (1.4A) (1608)
0F402 1-576-407-21 FUSE, MICRO (1.4A) (1608)
0F403 1-576-407-21 FUSE, MICRO (1.4A) (1608)
0F404 1-576-407-21 FUSE, MICRO (1.4A) (1608)
0F405 1-576-407-21 FUSE, MICRO (1.4A) (1608)
0F406 1-576-407-21 FUSE, MICRO (1.4A) (1608)
< COIL >
L401 1-412-056-11 INDUCTOR 4.7uH
< LINE FILTER >
LF401 1-411-957-11 FILTER, COMMON MODE
(TRV725E/TRV730E/TRV828E/TRV830E)
< TRANSISTOR >
Q401 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
Q402 8-729-051-49 TRANSISTOR HAT1054R-EL
Q403 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q404 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q405 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q408 8-729-051-49 TRANSISTOR HAT1054R-EL
Q409 8-729-023-89 TRANSISTOR 2SJ305(TE85L)
Q410 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q411 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q412 8-729-023-89 TRANSISTOR 2SJ305(TE85L)
< RESISTOR >
R401 1-216-821-11 METAL CHIP 1K 5% 1/16W
R402 1-216-295-11 SHORT 0
R403 1-216-821-11 METAL CHIP 1K 5% 1/16W
R406 1-216-853-11 METAL CHIP 470K 5% 1/16W
R407 1-216-857-11 METAL CHIP 1M 5% 1/16W
R408 1-216-150-91 RES-CHIP 10 5% 1/8W
R409 1-216-821-11 METAL CHIP 1K 5% 1/16W
R410 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R420 1-216-821-11 METAL CHIP 1K 5% 1/16W
R421 1-216-821-11 METAL CHIP 1K 5% 1/16W
R422 1-216-857-11 METAL CHIP 1M 5% 1/16W
R423 1-216-809-11 METAL CHIP 100 5% 1/16W
R424 1-216-841-11 METAL CHIP 47K 5% 1/16W
R425 1-216-809-11 METAL CHIP 100 5% 1/16W
R426 1-216-857-11 METAL CHIP 1M 5% 1/16W
R427 1-216-841-11 METAL CHIP 47K 5% 1/16W
R429 1-216-296-11 SHORT 0 (TRV730/TRV828/TRV830)
R430 1-216-296-11 SHORT 0 (TRV730/TRV828/TRV830)
************************************************************
A-7074-757-A LB-071 (GSB) BOARD, COMPLETE
****************************
(Ref. No.;10000 Series)
< CAPACITOR >
C702 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CONNECTOR >
CN701 1-779-334-11 CONNECTOR, FFC/FPC 20P
CN702 1-573-356-21 CONNECTOR, FFC/FPC 16P
CN702 1-691-354-21 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
0 D701 8-719-082-33 DIODE NSCW100-T38
D702 8-719-074-30 DIODE SML-310LTT86
< IC >
IC701 8-759-581-11 IC NJM2125F(TE2)
< TRANSISTOR >
Q701 8-759-054-48 TRANSISTOR UP04601008S0
Q702 8-729-054-45 TRANSISTOR UP04312008S0
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
