Sony DCR-TRV725E - PD-139

6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC5501 8-759-660-92 IC RB5P003AM1
IC5502 8-759-714-77 IC LZ9FF474
IC5601 8-759-564-49 IC TC7W53FU(TE12R)
IC5602 8-759-075-70 IC TA75S393F-TE85R
IC5701 8-759-573-02 IC BU9735K-E2
< COIL >
L5501 1-469-525-91 INDUCTOR 10uH
L5505 1-412-956-21 INDUCTOR 27uH
L5601 1-419-387-21 INDUCTOR 100uH
< TRANSISTOR >
Q5502 8-729-041-23 TRANSISTOR MGSF1P02LT1
Q5509 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q5510 8-759-054-48 TRANSISTOR UP04601008S0
Q5511 8-759-054-48 TRANSISTOR UP04601008S0
Q5601 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q5602 8-729-039-43 TRANSISTOR FP216-TL
Q5603 8-729-054-45 TRANSISTOR UP04312008S0
< RESISTOR >
R5501 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5503 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R5505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R5506 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R5507 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5508 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5509 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5510 1-216-843-11 METAL CHIP 68K 5% 1/16W
R5511 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5512 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5513 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5515 1-216-864-91 SHORT 0
R5516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5521 1-216-864-91 SHORT 0
R5523 1-216-809-11 METAL CHIP 100 5% 1/16W
R5524 1-216-809-11 METAL CHIP 100 5% 1/16W
R5525 1-216-809-11 METAL CHIP 100 5% 1/16W
R5551 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5553 1-216-821-11 METAL CHIP 1K 5% 1/16W
R5557 1-216-864-91 SHORT 0
R5562 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5563 1-216-841-11 METAL CHIP 47K 5% 1/16W
R5564 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5565 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5569 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5570 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5571 1-216-857-11 METAL CHIP 1M 5% 1/16W
R5572 1-216-821-11 METAL CHIP 1K 5% 1/16W
R5573 1-216-864-91 SHORT 0
R5574 1-216-864-91 SHORT 0
R5575 1-216-864-91 SHORT 0
R5609 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5610 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5611 1-216-848-11 METAL CHIP 180K 5% 1/16W
R5612 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R5614 1-216-833-11 METAL CHIP 10K 5% 1/16W
R5616 1-216-809-11 METAL CHIP 100 5% 1/16W
R5617 1-216-837-11 METAL CHIP 22K 5% 1/16W
R5618 1-216-817-11 METAL CHIP 470 5% 1/16W
R5712 1-216-855-11 METAL CHIP 680K 5% 1/16W
< TRANSFORMER >
0 T5601 1-435-227-11 TRANSFORMER, INVERTER
************************************************************
A-7074-674-A PD-139 (Z12) BOARD, COMPLETE
(TRV828/TRV828E/TRV830/TRV830E)
**************************************
A-7074-727-A PD-139 (X12) BOARD, COMPLETE
(TRV725E/TRV730E:AEP,UK)
**************************************
A-7074-786-A PD-139 (X6) BOARD, COMPLETE
(TRV730E:E,HK,AUS)
**************************************
(Ref. No.;10000 Series)
< CAPACITOR >
C5501 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C5503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5509 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C5510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C5512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5515 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C5516 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
(TRV725E/730E:AEP,UK)
C5516 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
(TRV730E:E,HK,AUS)
C5516 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(TRV828/TRV828E/TRV830/TRV830E)
C5517 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5518 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5519 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5532 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5533 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5534 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C5536 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5538 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5540 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5602 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5604 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C5605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
0 C5607 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C5704 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
PD-138 PD-139
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
