2-16E
The flexible boards contained in the mechanism deck and that in the zoom lens are not shown.
2-17.FLEXIBLE BOARDS LOCATION
FP-268
FP-264
FP-317
FP-319
(MEMORY STICK CONNECTOR)
FP-316
FP-342
CONTROL SWITCH BLOCK
(SS-1380)
CONTROL SWITCH BLOCK
(SE-1380)
FFC-001
