6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
CND : Canadian model
HK : Hong Kong model
AUS : Australian model
CN : Chinese model
KR : Korea model
A-7074-755-A CD-329 BOARD, COMPLETE
**********************
(Ref. No.;10000 Series)
(IC3401 is not included in this complete board)
< CAPACITOR >
C3401 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C3402 1-164-870-11 CERAMIC CHIP 68PF 5% 16V
C3403 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3406 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C3407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3410 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C3411 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C3412 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3413 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3414 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3415 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN3401 1-779-336-11 CONNECTOR, FFC/FPC 24P
< FERRITE BEAD >
FB3401 1-414-445-11 FERRITE 0UH
< IC >
IC3401 A-7031-073-A CCD BLOCK ASSY (CCD IMAGER)
IC3402 8-759-638-68 IC AD80017JRURL
< COIL >
L3401 1-469-525-91 INDUCTOR 10uH
L3402 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q3401 8-729-037-74 TRANSISTOR UN9213J-(TX).SO
Q3402 8-729-050-22 TRANSISTOR 2SC4250(T5LSONY1)
CD-329 CF-084
Be sure to read “Precautions upon replacing CCD imager”
on page 4-10 when changing the CCD imager.
< RESISTOR >
R3401 1-218-990-11 SHORT 0
R3402 1-218-990-11 SHORT 0
R3403 1-218-990-11 SHORT 0
R3404 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R3407 1-216-864-11 METAL CHIP 0 5% 1/16W
R3407 1-216-864-91 SHORT 0
************************************************************
A-7074-756-A CF-084 (SB) BOARD, COMPLETE
**************************
(Ref. No.;10000 Series)
< BATTERY >
BT101 1-756-141-11 BATTERY, MANGANESE LITHIUM
< CAPACITOR >
C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C201 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C202 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C209 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C210 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C212 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C213 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C215 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C216 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C217 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C218 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C219 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C220 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C221 1-109-994-11 CERAMIC CHIP 2.2uF 10% 10V
< CONNECTOR >
CN102 1-785-760-21 CONNECTOR, FFC/FPC (ZIF) 45P
CN103 1-794-058-21 PIN, CONNECTOR (PC BOARD) 6P
CN104 1-779-328-21 CONNECTOR, FFC/FPC 8P
* CN105 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
CN106 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN107 1-784-320-11 CONNECTOR, FFC/FPC 6P
CN201 1-779-334-11 CONNECTOR, FFC/FPC 20P
