6-13
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FP-270 FP-272
A-7074-648-A FP-270 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< DIODE >
D101 8-719-069-85 DIODE UDZSTE-178.2B
D102 8-719-069-85 DIODE UDZSTE-178.2B
< JACK >
J101 1-770-860-11 CONNECTOR, S TERMINAL (S VIDEO)
J102 1-778-040-11 JACK, SMALL TYPE (AUDIO/VIDEO)
< RESISTOR >
R101 1-216-864-91 SHORT 0
R102 1-216-864-91 SHORT 0
R104 1-216-864-91 SHORT 0
R105 1-216-864-91 SHORT 0
R107 1-216-864-91 SHORT 0
R108 1-216-864-91 SHORT 0
R109 1-216-864-91 SHORT 0
R110 1-107-826-11 CERAMIC CHIP 0.1UF 10% 16V
R111 1-107-826-11 CERAMIC CHIP 0.1UF 10% 16V
< VARISTOR >
VDR101 1-803-974-21 VARISTOR, CHIP
VDR102 1-803-974-21 VARISTOR, CHIP
VDR103 1-803-974-21 VARISTOR, CHIP
VDR104 1-803-974-21 VARISTOR, CHIP
VDR105 1-803-974-21 VARISTOR, CHIP
************************************************************
A-7074-650-A FP-272 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< CONNECTOR >
CN202 1-779-369-11 CONNECTOR, SQUARE TYPE(INDI)4P
(DV IN/OUT)
< DIODE >
D202 8-719-064-61 DIODE 01BZA8.2(TE85L)
< JACK >
J201 1-793-995-11 JACK, SUPER SMALL TYPE (LANC)
< RESISTOR >
R204 1-216-817-11 METAL CHIP 470 5% 1/16W
R205 1-216-864-91 SHORT 0
R207 1-216-864-91 SHORT 0
< VARISTOR >
VDR201 1-801-923-11 VARISTOR, CHIP
************************************************************
A-7074-651-A FP-273 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< JACK >
J301 1-695-514-21 JACK, SMALL TYPE, 1P (HEADPHONES)
J302 1-691-737-11 JACK, SMALL TYPE (MIC(PLUG IN POWER))
< PHOTO INTERRUPTER >
PH301 8-759-014-54 HIC CNA1312K01S0
PH302 8-759-014-54 HIC CNA1312K01S0
************************************************************
A-7074-654-A FP-283 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< SWITCH >
S601 1-771-483-81 SWITCH, PUSH (1 KEY) (PANEL REVERSE)
************************************************************
A-7074-761-A FP-315 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< DIODE >
D401 8-719-074-30 DIODE SML-310LTT86
D402 8-719-064-61 DIODE 01BZA8.2(TE85L)
< RESISTOR >
R403 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R404 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R405 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R406 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R407 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R408 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R409 1-216-821-11 METAL CHIP 1K 5% 1/16W
R410 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
< SWITCH >
S401 1-771-138-82 SWITCH, KEY BOARD (STOP)
S402 1-771-138-82 SWITCH, KEY BOARD (SUPER NIGHT SHOT)
S403 1-771-138-82 SWITCH, KEY BOARD (FF)
S404 1-771-138-82 SWITCH, KEY BOARD (PAUSE)
S405 1-771-138-82 SWITCH, KEY BOARD (SUPER LASER LINK)
S406 1-771-138-82 SWITCH, KEY BOARD (REC)
(TRV730/TRV730E/TRV828/TRV828E/TRV830/TRV830E)
S407 1-771-138-82 SWITCH, KEY BOARD (REW)
S408 1-771-138-82 SWITCH, KEY BOARD (REC)
(TRV730/TRV730E/TRV828/TRV828E/TRV830/TRV830E)
S409 1-771-138-82 SWITCH, KEY BOARD (PLAY)
************************************************************
A-7074-762-A FP-318 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< SWITCH >
S501 1-762-650-21 SWITCH, SLIDE (FOCUS AUTO/MANUAL)
************************************************************
A-7074-763-A FP-332 BOARD, COMPLETE
**********************
(Ref. No.;20000 Series)
< CAPACITOR >
C201 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN201 1-794-962-11 CONNECTOR, SQUARE TYPE(USB 5P) (USB)
FP-273 FP-283 FP-315 FP-318 FP-332
