Sony SA-WST9 User Manual

HT-ST9
18
2-9. CHASSIS BLOCK-2
1 L-ch speaker cable
connector
(CN7002)
qa
chassis block
0 five screws
(BVTP3 u 8)
– Rear view –
Note 1:
Lay a soft piece of cloth
under the unit to avoid
damaging the grille assy.
2 R-ch speaker cable
connector
(CN7003)
4 center speaker
cable connector
(CN7007)
5 REPEATER_REP board
cable connector
(CN1703)
7 WS board cable connector
(CN702)
8 WLAN/BT card cable connector
(CN502)
9 DISPLAY board FFC (22P) (FFC4)
(CN3003)
6 USB board cable
connector
(CN501)
3 center speaker cable
connector
(CN7005)
Right side
Top side
Left side
Bottom side
Insert only part way.Insert straight into
the interior.
connector
Insert at a slant.
connector
connector
connector
connector connector
OK NG NG
 How to install the connector
Insert the connector straight into the interior.
There is a possibility that using this unit without
the connector correctly installed will damage it.
colored line
Insert straight into the interior.
flexible flat
cable
connector
OK
colored line
Insert at a slant.
flexible flat
cable
connector
NG
 How to install the flexible flat cable
When installing the flexible flat cable, ensure that
the colored line is parallel to the connector after insertion.
Note 3:
When installing screws (BVTP3 × 8), follow the installing procedure in the numerical order given.
1
2
4
3
5
OK
NG
Note 2:
When installing the chassis block, pass
the REPEATER_REP board cable
underneath the bracket (I/O) assy.
 :ire settinJ
cushion
bracket
(I/O)
assy
wires
terminal side
