82
HT-ST9
SECTION 7
ELECTRICAL PARTS LIST
A-2054-809-A AMP BOARD, COMPLETE (Except LA)
(See Note 1)
A-2080-753-A AMP BOARD, COMPLETE (LA) (See Note 1)
********************
< CAPACITOR >
C7001 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C7002 1-116-711-11 CERAMIC CHIP 22uF 20% 16V
C7003 1-165-492-21 ELECT CHIP 100uF 20% 10V
C7004 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C7005 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C7006 1-118-399-11 CERAMIC CHIP 0.0022uF 10% 50V
C7007 1-118-418-11 CERAMIC CHIP 22uF 20% 6.3V
C7008 1-118-418-11 CERAMIC CHIP 22uF 20% 6.3V
C7009 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7010 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C7011 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C7012 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
C7013 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7014 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7015 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C7016 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C7017 1-120-061-11 ELECT CHIP 470uF 20% 35V
(See Note 2)
C7018 1-118-398-11 CERAMIC CHIP 0.0027uF 10% 50V
C7019 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7020 1-120-061-11 ELECT CHIP 470uF 20% 35V
(See Note 2)
C7021 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C7022 1-164-864-11 CERAMIC CHIP 39PF 5% 50V
C7023 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7024 1-128-991-21 ELECT CHIP 10uF 20% 50V
C7025 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7026 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7027 1-128-992-21 ELECT CHIP 47uF 20% 25V
C7028 1-114-484-11 ELECT CHIP 100uF 20% 16V
C7029 1-118-403-11 CERAMIC CHIP 0.001uF 10% 50V
C7030 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C7031 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C7032 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C7033 1-120-003-11 FILM CHIP 1uF 20% 35V
C7034 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C7035 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C7036 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C7037 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7038 1-120-061-11 ELECT CHIP 470uF 20% 35V
(See Note 2)
C7039 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C7040 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C7041 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C7042 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7043 1-120-003-11 FILM CHIP 1uF 20% 35V
C7044 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C7045 1-120-003-11 FILM CHIP 1uF 20% 35V
C7046 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C7047 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
* C7048 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C7049 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7050 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C7051 1-120-061-11 ELECT CHIP 470uF 20% 35V
(See Note 2)
C7052 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7053 1-120-003-11 FILM CHIP 1uF 20% 35V
C7054 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C7055 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
* C7056 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
C7057 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C7058 1-116-732-11 CERAMIC CHIP 2.2uF 20% 6.3V
C7059 1-116-716-11 CERAMIC CHIP 10uF 10% 16V
C7060 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7061 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
C7063 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C7064 1-118-391-11 CERAMIC CHIP 0.01uF 10% 50V
C7065 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C7066 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C7067 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
C7068 1-127-948-21 FILM CHIP 0.0047uF 5% 16V
C7069 1-120-061-11 ELECT CHIP 470uF 20% 35V
(See Note 2)
C7070 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C7071 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
* C7072 1-116-735-11 CERAMIC CHIP 1uF 10% 16V
* C7074 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C7075 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C7076 1-118-365-11 CERAMIC CHIP 0.047uF 10% 50V
* C7077 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
Note 1: When the complete AMP board is replaced, refer to “NOTE OF RE-
PLACING THE IC7004, IC7005, IC7007 AND IC7008 ON THE
AMP BOARD AND THE COMPLETE AMP BOARD” on page 6.
Note 2: When C7017, C7020, C7038, C7051 and C7069 on the AMP
board are replaced, refer to “BOND FIXATION OF ELEC-
TRIC PARTS” on page 9.
AMP
Ver. 1.1
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
