HT
-ST9
42
2-34.
LOUDSPEAKER (SP9, SP10) (CENTER)-1
•
Continued on 2-35 (page 43).
2
cushion
(absorbent)
2
cushion
(absorbent)
2
cushion
(absorbent)
2
cushion
(absorbent)
– Center speaker block front view –
Right side
T
op side
Left side
Bottom side
Note:
When installing screws, follow the installing procedure in the numerical order given.
1
two
screws
(3.5)
1
two
screws
(3.5)
1
screw
(3.5)
1
screw
(3.5)
1
screw
(3.5)
1
screw
(3.5)
6
7
3
2
4
1
8
5
41
43
