Engine General Information and Diagnosis: 1A-160
DTC P0617: Starter Relay Circuit High
S5JB0A1104055
Wiring Diagram
Refer to “DTC P0616: Starter Relay Circuit Low: ”.
DTC Detecting Condition and Trouble Area
DTC Confirmation Procedure
1) With ignition switch turned OFF, connect scan tool.
2) Turn ON ignition switch and clear DTC using scan tool.
3) Start engine and run it at idle for 3 min. or more.
4) Check DTC and pending DTC.
DTC Troubleshooting
NOTE
Before this trouble shooting is performed, read the precautions for DTC troubleshooting referring to
“Precautions For DTC Troubleshooting: ”.
DTC detecting condition Trouble area
Engine starter signal is high voltage for 180 seconds
continuously while engine is running.
(2 driving cycle detection logic)
Engine starter signal circuit
•ECM
Step Action Yes No
1 Was “Engine and Emission Control System Check”
performed?
Go to Step 2. Go to “Engine and
Emission Control
System Check: ”.
2 Starter signal check
1) Turn OFF ignition switch.
2) Remove ECM from its bracket with ECM connectors
connected.
3) Start engine, measure voltage between “C37-22”
terminal of ECM connector and vehicle body ground.
Is voltage 0 – 1 V?
Intermittent trouble.
Check for intermittent
referring to “Intermittent
and Poor Connection
Inspection: in Section
00”. If OK, substitute a
known-good ECM and
recheck.
Go to Step 3.
3 Wire circuit check
1) Disconnect starting motor control relay in fuse box No.2
with ignition switch turned OFF.
2) Check for proper connection to starting motor control
relay at “BLK/YEL”, “BLK/RED” and “BLK” (for M/T
model) wire terminals.
3) Disconnect connector from starting motor.
4) Measure voltage between “C37-22” terminal of ECM
connector and vehicle body ground with ignition switch
turned ON.
Is voltage 0 – 1 V?
Go to Step 4. “BLK/YEL” wire is
shorted to power circuit.
If wires are OK,
substitute a known good
ECM and recheck.
4 Wire circuit check
1) Measure voltage between “BLK/YEL” wire terminal for
coil side of starting motor control relay connector coil
side and vehicle body ground with ignition switch turned
ON.
Is voltage 0 – 1 V?
Check starting motor
control relay. If OK,
substitute a known-
good ECM and recheck.
Check ignition switch
referring to “Ignition
Switch Inspection: in
Section 9C”.
If ignition switch is OK,
check for short circuit
between ignition switch
and starting motor
control relay to power
circuit.
