Engine General Information and Diagnosis: 1A-36
Fail-Safe Table
S5JB0A1104006
When any of the following DTCs is detected, ECM enters fail-safe mode as long as malfunction continues to exist but
that mode is canceled when ECM detects normal condition after that.
DTC No. Detected item Fail-safe operation
) P0030 HO2S heater control circuit (Sensor-1)
ECM stops air/fuel ratio control.) P0031 HO2S heater control circuit low (Sensor-1)
) P0032 HO2S heater control circuit high (Sensor-1)
) P0102 Mass air flow circuit low input • ECM controls injector drive time (fuel injection
volume) according to throttle valve opening
(closed throttle position or not).
• ECM stops EGR control.
) P0103 Mass air flow circuit high input
) P0112 Intake air temperature sensor circuit low ECM controls actuators assuming that intake air
temperature is 20 °C (68 °F).) P0113 Intake air temperature sensor circuit high
) P0117 Engine coolant temperature circuit low • ECM controls actuators assuming that engine
coolant temperature is 80 °C (176 °F).
• ECM operates radiator cooling fan.
) P0118 Engine coolant temperature circuit high
) P0122 Throttle position sensor (main) circuit low
• ECM turns off throttle actuator control relay and
throttle valve is fixed at the opening of about 7°
from its completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
• ECM stops air/fuel ratio control.
) P0123 Throttle position sensor (main) circuit high
• ECM turns off throttle actuator control relay and
throttle valve is fixed at the opening of about 7°
from its completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
• ECM stops air/fuel ratio control.
) P0131 O2 sensor (HO2S) circuit low voltage (Sensor-1)
ECM stops air/fuel ratio control.
) P0132 O2 sensor (HO2S) circuit high voltage (Sensor-1)
) P0134
O2 sensor (HO2S) circuit no activity detected
(Sensor-1)
) P0222 Throttle position sensor (sub) circuit low • ECM turns off throttle actuator control relay and
throttle valve is fixed at the opening of about 7°
from its completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
) P0223 Throttle position sensor (sub) circuit high
) P0335 Crankshaft position sensor circuit Ignition timing is fixed.
) P0500 Vehicle speed sensor
ECM controls actuators assuming that vehicle
speed is 0 km/h (0 mile/h).
) P2101
Throttle actuator control motor circuit range /
performance
• ECM turns off throttle actuator control relay and
throttle valve is fixed at the opening of about 7°
from its completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
) P2102 Throttle actuator control motor circuit low
) P2103 Throttle actuator control motor circuit high ECM controls fuel cut at specified engine speed.
) P2111 Throttle actuator control system – stuck open
• Throttle valve is fixed at the opening of about 7
°
from it
s
completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
) P2119
Throttle actuator control throttle body range /
performance
• ECM turns off throttle actuator control relay and
throttle valve is fixed at the opening of about 7°
from its completely closed position (default
opening).
• ECM controls fuel cut at specified engine speed.
