Engine General Information and Diagnosis: 1A-202
DTC P2128: Pedal Position Sensor (Sub) Circuit High Input
S5JB0A1104085
Wiring Diagram
Refer to “DTC P2122: Pedal Position Sensor (Main) Circuit Low Input: ”.
DTC Detecting Condition and Trouble Area
6 Wire harness check
1) Disconnect connectors from ECM with ignition switch
turned OFF.
2) Measure resistance between “E23-53” terminal of ECM
connector and engine ground.
Is resistance infinity?
Substitute a known-
good ECM and recheck.
“ORN/BLU” wire is
shorted to ground
circuit.
7 Wire harness check
1) Disconnect connectors from ECM with ignition switch
turned OFF.
2) Check for proper connection of ECM connector at “E23-
54”, “E23-52” and “E23-51” terminals.
3) If OK, measure resistance between “BLU/GRN” wire
terminal of accelerator pedal position (APP) sensor
assembly connector and vehicle body ground.
Is resistance infinity?
Go to Step 8. “BLU/GRN” wire is
shorted to ground
circuit.
8 Wire harness check
1) Measure resistance between “E23-52” and each “E23-
54”, “E23-51” terminals of ECM connector with ignition
switch turned OFF.
Is each resistance infinity?
Go to Step 9. “BLU/GRN” wire is
shorted to “ORN” wire
and/or “BLU/YEL” wire
circuit.
9 Wire harness check
1) Measure resistance between “BLU/GRN” wire terminal
of accelerator pedal position (APP) sensor assembly
connector and “E23-52” terminal of ECM connector with
ignition switch turned OFF.
Is resistance below 3
Ω
?
Go to Step 10. “BLU/GRN” wire is open
or high resistance
circuit.
10 Accelerator pedal position (APP) sensor assembly
check
1) Check accelerator pedal position sensor (sub) referring
to “Accelerator Pedal Position (APP) Sensor Assembly
Inspection: in Section 1C”.
Is output voltage within specified value?
Substitute a known-
good ECM and recheck.
Replace accelerator
pedal position (APP)
sensor assembly.
Step Action Yes No
DTC detecting condition Trouble area
Output voltage of accelerator pedal position sensor (sub)
is more than specified value for 0.5 seconds continuously.
(1 driving detection logic)
• Accelerator pedal position (APP) sensor (sub) circuit
• Accelerator pedal position (APP) sensor assembly
•ECM
• Incorrect mounting of accelerator (APP) sensor
assembly
To Next Page
