1F-14 Engine Cooling System:
Water Pump Inspection
S5JB0A1606018
CAUTION
!
Do not disassemble water pump.
If any repair is required on pump, replace it
as assembly.
Rotate water pump by hand to check for smooth
operation. If pump does not rotate smoothly or makes
abnormal noise, replace it.
Specifications
Tightening Torque Specifications
S5JB0A1607001
NOTE
The specified tightening torque is also described in the following.
“Cooling System Components: ”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information: in Section 0A”.
Special Tools and Equipment
Recommended Service Material
S5JB0A1608001
I2RH0B160019-01
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Water pump bolt and nut 25 2.5 18.0 )
Water pump bolt 25 2.5 18.0 )
Material SUZUKI recommended product or Specification Note
Water tight sealant SUZUKI Bond No.1207F P/No.: 99000–31250 )
To Next Page
