1-6 GENERAL INFORMATION
INFORMATION LABELS
10 mm
(0.4 in)
10 mm
(0.4 in)
10 mm
(0.4 in)
10 mm
(0.4 in)
28 mm
(1.1 in)
28 mm
(1.1 in)
10 mm (0.4 in)
10 mm (0.4 in)
(E-28 Only)
(For E-03, 33)
5 mm
(0.2 in)
Document tray
(Except E-28)
(Except E-03, 33)
(Attached on the left frame pipe)
(Attached on the right side
of the rear fender)
1 Noise label (For E-03, 33)
2 Information label (For E-03, 28, 33)
3 Vacuum hose routing label (For E-33)
4 Fuel caution label (For E-02, 24)
5 Manual notice label (For E-03, 33)
6 Warning screen label
7 Warning steering label
8 Tire pressure label
9 Warning safety label
0 ICES Canada label (For E-28)
A ID plate (Except E-03, 28, 33)
B Safety plate (For E-03, 28, 33)
